LED Strip

The LSL LED strip is available in a wide variety of lumen packages and lengths, which allows for flexibility in design and helps maximize energy savings. Frosted diffuser lenses are available to help minimize glare and improve aesthetics. Occupancy sensors, photocells, emergency packs and step-down transformers are among the options available. All LSLs feature field-replaceable LED boards and drivers. The LSL is assembled in the USA.

  • Applications: Suitable for most commercial, industrial and institutional applications - office, retail, warehouse, coves, valences
  • Lumen Output: From 800 lm in the 2-foot version to 18,000 lm in the 8-footer
  • Max Lumens Per Watt: 150
  • Size Options: 2-foot, 3-foot, 4-foot, 6-foot, 8-foot
  • Predicted L70 Lifetime: Up to 189,000 hours (calculated)
  • Warranty: 5 year limited system warranty. 10 year extended warranty available on specific models
  • Certifications: UL 1598 listed for US and Canada, suitable for damp locations. DesignLights Consortium qualified on specific configurations
  • Assembled in America: BAA compliant options are available
https://unamilighting.com/wp-content/uploads/2018/04/LSL-1B.jpg
LSL 4-footer with frosted diffuser lens
https://unamilighting.com/wp-content/uploads/2018/04/LSL-1A.jpg
LSL 4-footer with frosted diffuser lens
https://unamilighting.com/wp-content/uploads/2018/04/LSL8-1.jpg
LSL 8-footer with frosted diffuser lens
https://unamilighting.com/wp-content/uploads/2018/04/LSL-2.jpg
LSL 4-footer
https://unamilighting.com/wp-content/uploads/2018/04/LSL8-2.jpg
LSL 8-footer

LSL Performance Chart

Catalog #
QPL/UL Reference #
SizeLumensWattsLPWCRI / Color TempVoltages AvailableDLC ListedPredicted L70 LifetimeEquivalency*
LSL 2 LW UV 835

ECL 2 LW UV 835

2-foot8378104.780 CRI / 3500K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 1-lamp F17 T8 with LBF in a 2-foot strip
LSL 2 LW UV 840

ECL 2 LW UV 840

2-foot8638107.980 CRI / 4000K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 1-lamp F17 T8 with LBF in a 2-foot strip
LSL 2 LW UV 850

ECL 2 LW UV 850

2-foot8898111.180 CRI / 5000K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 1-lamp F17 T8 with LBF in a 2-foot strip
LSL 2 MD UV 835

ECL 2 MD UV 835

2-foot1,95017.5111.480 CRI / 3500K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 2-lamp F17 T8 with NBF, or 1-lamp F24 T5HO, in a 2-foot strip
LSL 2 MD UV 840

ECL 2 MD UV 840

2-foot2,01117.5114.980 CRI / 4000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 2-lamp F17 T8 with NBF, or 1-lamp F24 T5HO, in a 2-foot strip
LSL 2 MD UV 850

ECL 2 MD UV 850

2-foot2,07117.5118.380 CRI / 5000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 2-lamp F17 T8 with NBF, or 1-lamp F24 T5HO, in a 2-foot strip
LSL 2 HI UV 835

ECL 2 HI UV 835

2-foot3,08523134.180 CRI / 3500K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 2-lamp F24T5HO in a 2-foot strip
LSL 2 HI UV 840

ECL 2 HI UV 840

2-foot3,18023138.380 CRI / 4000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 2-lamp F24T5HO in a 2-foot strip
LSL 2 HI UV 850

ECL 2 HI UV 850

2-foot3,27523142.480 CRI / 5000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 2-lamp F24T5HO in a 2-foot strip
LSL 2 VH UV 835

ECL 2 VH UV 835

2-foot3,96332123.980 CRI / 3500K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 3-lamp F17 T8 with HBF in a 2-foot strip
LSL 2 VH UV 840

ECL 2 VH UV 840

2-foot4,08632127.780 CRI / 4000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 3-lamp F17 T8 with HBF in a 2-foot strip
LSL 2 VH UV 850

ECL 2 VH UV 850

2-foot4,20832131.580 CRI / 5000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 3-lamp F17 T8 with HBF in a 2-foot strip
LSL 3 LW UV 835

ECL 3 LW UV 835

3-foot1,24111112.880 CRI / 3500K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 1-lamp F25 T8 with LBF in a 3-foot strip
LSL 3 LW UV 840

ECL 3 LW UV 840

3-foot1,27911116.380 CRI / 4000K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 1-lamp F25 T8 with LBF in a 3-foot strip
LSL 3 LW UV 850

ECL 3 LW UV 850

3-foot1,31811119.880 CRI / 5000K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 1-lamp F25 T8 with LBF in a 3-foot strip
LSL 3 MD UV 835

ECL 3 MD UV 835

3-foot3,18323138.480 CRI / 3500K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 2-lamp F25 T8 with NBF in a 3-foot strip
LSL 3 MD UV 840

ECL 3 MD UV 840

3-foot3,28223142.780 CRI / 4000K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 2-lamp F25 T8 with NBF in a 3-foot strip
LSL 3 MD UV 850

ECL 3 MD UV 850

3-foot3,3802314780 CRI / 5000K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 2-lamp F25 T8 with NBF in a 3-foot strip
LSL 4 LW UV 835

ECL 4 LW UV 835

4-foot2,3051812880 CRI / 3500K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 1-lamp F32 T8 with NBF in a 4-foot strip
LSL 4 LW UV 840
ECL 4 LW UV 840

4-foot2,3761813280 CRI / 4000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 1-lamp F32 T8 with NBF in a 4-foot strip
LSL 4 LW UV 850
ECL 4 LW UV 850

4-foot2,4471813680 CRI / 5000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 1-lamp F32 T8 with NBF in a 4-foot strip
LSL 4 MD UV 835
ECL 4 MD UV 835

4-foot3,83232119.780 CRI / 3500K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 2-lamp F32 T8 with NBF, or 1-lamp F54 T5HO, in a 4-foot strip
LSL 4 MD UV 840
ECL 4 MD UV 840

4-foot3,95032123.480 CRI / 4000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 2-lamp F32 T8 with NBF, or 1-lamp F54 T5HO, in a 4-foot strip
LSL 4 MD UV 850
ECL 4 MD UV 850

4-foot4,06932127.180 CRI / 5000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 2-lamp F32 T8 with NBF, or 1-lamp F54 T5HO, in a 4-foot strip
LSL 4 MH UV 835
ECL 4 MH UV 835

4-foot4,82936134.180 CRI / 3500K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 3-lamp F32 T8 with LBF in a 4-foot strip
LSL 4 MH UV 840
ECL 4 MH UV 840

4-foot4,97836138.380 CRI / 4000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 3-lamp F32 T8 with LBF in a 4-foot strip
LSL 4 MH UV 850
ECL 4 MH UV 850

4-foot5,12836142.480 CRI / 5000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 3-lamp F32 T8 with LBF in a 4-foot strip
LSL 4 HI UV 835
ECL 4 HI UV 835

4-foot6,70546145.880 CRI / 3500K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F32 T8 with LBF in a 4-foot strip
LSL 4 HI UV 840
ECL 4 HI UV 840

4-foot6,91346150.380 CRI / 4000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F32 T8 with LBF in a 4-foot strip
LSL 4 HI UV 850
ECL 4 HI UV 850

4-foot7,12046154.880 CRI / 5000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F32 T8 with LBF in a 4-foot strip
LSL 4 VH UV 835
ECL 4 VH UV 835

4-foot8,90168130.980 CRI / 3500K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F32 T8 with HBF in a 4-foot strip
LSL 4 VH UV 840
ECL 4 VH UV 840

4-foot9,17768134.980 CRI / 4000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F32 T8 with HBF in a 4-foot strip
LSL 4 VH UV 850
ECL 4 VH UV 850

4-foot9,4526813980 CRI / 5000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F32 T8 with HBF in a 4-foot strip
LSL 6 LW UV 835

ECL 6 LW UV 835

6-foot3,11922141.880 CRI / 3500K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 2-lamp F25 T8 with LBF in a 6-foot strip
LSL 6 LW UV 840

ECL 6 LW UV 840

6-foot3,21622146.280 CRI / 4000K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 2-lamp F25 T8 with LBF in a 6-foot strip
LSL 6 LW UV 850

ECL 6 LW UV 850

6-foot3,31222150.580 CRI / 5000K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 2-lamp F25 T8 with LBF in a 6-foot strip
LSL 6 MD UV 835

ECL 6 MD UV 835

6-foot6,4825412080 CRI / 3500K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 4-lamp F25 T8 with NBF in a 6-foot strip
LSL 6 MD UV 840

ECL 6 MD UV 840

6-foot6,68254123.780 CRI / 4000K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 4-lamp F25 T8 with NBF in a 6-foot strip
LSL 6 MD UV 850

ECL 6 MD UV 850

6-foot6,88354127.580 CRI / 5000K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 4-lamp F25 T8 with NBF in a 6-foot strip
LSL 6 HI UV 835

ECL 6 HI UV 835

6-foot9,85470140.880 CRI / 3500K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 6-lamp F25 T8 with NBF in a 6-foot strip
LSL 6 HI UV 840

ECL 6 HI UV 840

6-foot10,15970145.180 CRI / 4000K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 6-lamp F25 T8 with NBF in a 6-foot strip
LSL 6 HI UV 850

ECL 6 HI UV 850

6-foot10,46370149.580 CRI / 5000K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 6-lamp F25 T8 with NBF in a 6-foot strip
LSL 6 VH UV 835

ECL 6 VH UV 835

6-foot12,42395130.880 CRI / 3500K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 8-lamp F25 T8 with NBF in a 6-foot strip
LSL 6 VH UV 840

ECL 6 VH UV 840

6-foot12,80795134.880 CRI / 4000K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 8-lamp F25 T8 with NBF in a 6-foot strip
LSL 6 VH UV 850

ECL 6 VH UV 850

6-foot13,19295138.980 CRI / 5000K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 8-lamp F25 T8 with NBF in a 6-foot strip
LSL 8 LW UV 835
ECL 8 LW UV 835

8-foot4,24030141.380 CRI / 3500K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 2-lamp F32 T8 with NBF in an 8-foot strip
LSL 8 LW UV 840
ECL 8 LW UV 840

8-foot4,37130145.780 CRI / 4000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 2-lamp F32 T8 with NBF in an 8-foot strip
LSL 8 LW UV 850
ECL 8 LW UV 850

8-foot4,50330150.180 CRI / 5000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 2-lamp F32 T8 with NBF in an 8-foot strip
LSL 8 ML UV 835
ECL 8 ML UV 835

8-foot6,12544139.280 CRI / 3500K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 1-lamp F96 T8HO, or 1-lamp F96 T12HO, in an 8-foot strip
LSL 8 ML UV 840
ECL 8 ML UV 840

8-foot6,31444143.580 CRI / 4000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 1-lamp F96 T8HO, or 1-lamp F96 T12HO, in an 8-foot strip
LSL 8 ML UV 850
ECL 8 ML UV 850

8-foot6,50444147.880 CRI / 5000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 1-lamp F96 T8HO, or 1-lamp F96 T12HO, in an 8-foot strip
LSL 8 MD UV 835
ECL 8 MD UV 835

8-foot8,03364125.580 CRI / 3500K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F32 T8 with NBF, 2-lamp F54 T5HO, or 2-lamp F96 T8 in an 8-foot strip
LSL 8 MD UV 840
ECL 8 MD UV 840

8-foot8,28164129.480 CRI / 4000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F32 T8 with NBF, 2-lamp F54 T5HO, or 2-lamp F96 T8 in an 8-foot strip
LSL 8 MD UV 850
ECL 8 MD UV 850

8-foot8,53064133.380 CRI / 5000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F32 T8 with NBF, 2-lamp F54 T5HO, or 2-lamp F96 T8 in an 8-foot strip
LSL 8 MD HE UV 835
ECL 8 MD HE UV 835

8-foot8,0505614380 CRI / 3500K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F32 T8 with NBF, 2-lamp F54 T5HO, or 2-lamp F96 T8 in an 8-foot strip
LSL 8 MD HE UV 840
ECL 8 MD HE UV 840

8-foot8,29956147.480 CRI / 4000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F32 T8 with NBF, 2-lamp F54 T5HO, or 2-lamp F96 T8 in an 8-foot strip
LSL 8 MD HE UV 850
ECL 8 MD HE UV 850

8-foot8,54856151.980 CRI / 5000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F32 T8 with NBF, 2-lamp F54 T5HO, or 2-lamp F96 T8 in an 8-foot strip
LSL 8 MH UV 835
ECL 8 MH UV 835

8-foot10,7657813880 CRI / 3500K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F32 T8 with HBF, or 2-lamp F96 T12HO, in an 8-foot strip
LSL 8 MH UV 840
ECL 8 MH UV 840

8-foot11,09878142.380 CRI / 4000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F32 T8 with HBF, or 2-lamp F96 T12HO, in an 8-foot strip
LSL 8 MH UV 850
ECL 8 MH UV 850

8-foot11,43178146.580 CRI / 5000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F32 T8 with HBF, or 2-lamp F96 T12HO, in an 8-foot strip
LSL 8 HI UV 835
ECL 8 HI UV 835

8-foot12,41287141.280 CRI / 3500K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 2-lamp F96 T8HO in an 8-foot strip
LSL 8 HI UV 840
ECL 8 HI UV 840

8-foot12,79687147.180 CRI / 4000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 2-lamp F96 T8HO in an 8-foot strip
LSL 8 HI UV 850
ECL 8 HI UV 850

8-foot13,18087151.580 CRI / 5000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 2-lamp F96 T8HO in an 8-foot strip
LSL 8 VH UV 835
ECL 8 VH UV 835

8-foot17,316135128.380 CRI / 3500K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F54 T5HO in an 8-foot strip
LSL 8 VH UV 840
ECL 8 VH UV 840

8-foot17,852135132.280 CRI / 4000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F54 T5HO in an 8-foot strip
LSL 8 VH UV 850
ECL 8 VH UV 850

8-foot18,388135136.280 CRI / 5000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F54 T5HO in an 8-foot strip
LSL 2 LW UV FR 835

ECL 2 LW UV FR 835

2-foot8048100.580 CRI / 3500K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 1-lamp F17 T8 with LBF in a 2-foot strip
LSL 2 LW UV FR 840

ECL 2 LW UV FR 840

2-foot8288103.680 CRI / 4000K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 1-lamp F17 T8 with LBF in a 2-foot strip
LSL 2 LW UV FR 850

ECL 2 LW UV FR 850

2-foot8538106.780 CRI / 5000K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 1-lamp F17 T8 with LBF in a 2-foot strip
LSL 2 MD UV FR 835
ECL 2 MD UV FR 835

2-foot1,85217.5105.880 CRI / 3500K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 2-lamp F17 T8 with LBF, or 1-lamp F24 T5HO, in a 2-foot strip
LSL 2 MD UV FR 840

ECL 2 MD UV FR 840

2-foot1,91017.5109.180 CRI / 4000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 2-lamp F17 T8 with LBF, or 1-lamp F24 T5HO, in a 2-foot strip
LSL 2 MD UV FR 850

ECL 2 MD UV FR 850

2-foot1,96717.5112.480 CRI / 5000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 2-lamp F17 T8 with LBF, or 1-lamp F24 T5HO, in a 2-foot strip
LSL 2 HI UV FR 835

ECL 2 HI UV FR 835

2-foot2,96023128.780 CRI / 3500K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 2-lamp F17 T8 with HBF, or 2-lamp F24 T5HO, in a 2-foot strip
LSL 2 HI UV FR 840

ECL 2 HI UV FR 840

2-foot3,05223132.780 CRI / 4000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 2-lamp F17 T8 with HBF, or 2-lamp F24 T5HO, in a 2-foot strip
LSL 2 HI UV FR 850

ECL 2 HI UV FR 850

2-foot3,14323136.780 CRI / 5000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 2-lamp F17 T8 with HBF, or 2-lamp F24 T5HO, in a 2-foot strip
LSL 2 VH UV FR 835

ECL 2 VH UV FR 835

2-foot3,80432118.980 CRI / 3500K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 3-lamp F17 T8 with HBF in a 2-foot strip
LSL 2 VH UV FR 840

ECL 2 VH UV FR 840

2-foot3,92132122.580 CRI / 4000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 3-lamp F17 T8 with HBF in a 2-foot strip
LSL 2 VH UV FR 850

ECL 2 VH UV FR 850

2-foot4,03932126.280 CRI / 5000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 3-lamp F17 T8 with HBF in a 2-foot strip
LSL 3 LW UV FR 835

ECL 3 LW UV FR 835

3-foot1,19111108.380 CRI / 3500K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 1-lamp F25 T8 with LBF in a 3-foot strip
LSL 3 LW UV FR 840

ECL 3 LW UV FR 840

3-foot1,22811111.680 CRI / 4000K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 1-lamp F25 T8 with LBF in a 3-foot strip
LSL 3 LW UV FR 850

ECL 3 LW UV FR 850

3-foot1,2651111580 CRI / 5000K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 1-lamp F25 T8 with LBF in a 3-foot strip
LSL 3 MD UV FR 835

ECL 3 MD UV FR 835

3-foot3,05523132.880 CRI / 3500K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 2-lamp F25 T8 with NBF in a 3-foot strip
LSL 3 MD UV FR 840

ECL 3 MD UV FR 840

3-foot3,15023136.980 CRI / 4000K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 2-lamp F25 T8 with NBF in a 3-foot strip
LSL 3 MD UV FR 850

ECL 3 MD UV FR 850

3-foot3,24423141.180 CRI / 5000K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 2-lamp F25 T8 with NBF in a 3-foot strip
LSL 3 HI UV FR 835

ECL 3 HI UV FR 835

3-foot4,7113812480 CRI / 3500K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 3-lamp F25 T8 with NBF in a 3-foot strip
LSL 3 HI UV FR 840

ECL 3 HI UV FR 840

3-foot4,85738127.880 CRI / 4000K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 3-lamp F25 T8 with NBF in a 3-foot strip
LSL 3 HI UV FR 850

ECL 3 HI UV FR 850

3-foot5,00338131.680 CRI / 5000K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 3-lamp F25 T8 with NBF in a 3-foot strip
LSL 3 VH UV FR 835

ECL 3 VH UV FR 835

3-foot6,1766496.580 CRI / 3500K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 4-lamp F25 T8 with NBF in a 3-foot strip
LSL 3 VH UV FR 840

ECL 3 VH UV FR 840

3-foot6,3676499.580 CRI / 4000K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 4-lamp F25 T8 with NBF in a 3-foot strip
LSL 3 VH UV FR 850

ECL 3 VH UV FR 850

3-foot6,55864102.580 CRI / 5000K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 4-lamp F25 T8 with NBF in a 3-foot strip
LSL 4 LW UV FR 835

ECL 4 LW UV FR 835

4-foot2,21218122.980 CRI / 3500K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 1-lamp F32 T8 with NBF in a 4-foot strip
LSL 4 LW UV FR 840
ECL 4 LW UV FR 840

4-foot2,28018126.780 CRI / 4000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 1-lamp F32 T8 with NBF in a 4-foot strip
LSL 4 LW UV FR 850
ECL 4 LW UV FR 850

4-foot2,34918130.580 CRI / 5000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 1-lamp F32 T8 with NBF in a 4-foot strip
LSL 4 MD UV FR 835
ECL 4 MD UV FR 835

4-foot3,64032115.580 CRI / 3500K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 2-lamp F32 T8 with LBF, or 1-lamp F54 T5HO, in a 4-foot strip
LSL 4 MD UV FR 840
ECL 4 MD UV FR 840

4-foot3,75232119.180 CRI / 4000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 2-lamp F32 T8 with LBF, or 1-lamp F54 T5HO, in a 4-foot strip
LSL 4 MD UV FR 850
ECL 4 MD UV FR 850

4-foot3,86532122.780 CRI / 5000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 2-lamp F32 T8 with LBF, or 1-lamp F54 T5HO, in a 4-foot strip
LSL 4 MH UV FR 835
ECL 4 MH UV FR 835

4-foot4,63536128.780 CRI / 3500K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 3-lamp F32 T8 with LBF in a 4-foot strip
LSL 4 MH UV FR 840
ECL 4 MH UV FR 840

4-foot4,77836132.780 CRI / 4000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 3-lamp F32 T8 with LBF in a 4-foot strip
LSL 4 MH UV FR 850
ECL 4 MH UV FR 850

4-foot4,92136136.780 CRI / 5000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 3-lamp F32 T8 with LBF in a 4-foot strip
LSL 4 HI UV FR 835
ECL 4 HI UV FR 835

4-foot6,43646139.980 CRI / 3500K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F32 T8 with LBF in a 4-foot strip
LSL 4 HI UV FR 840
ECL 4 HI UV FR 840

4-foot6,63546144.280 CRI / 4000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F32 T8 with LBF in a 4-foot strip
LSL 4 HI UV FR 850
ECL 4 HI UV FR 850

4-foot6,83446148.680 CRI / 5000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F32 T8 with LBF in a 4-foot strip
LSL 4 VH UV FR 835
ECL 4 VH UV FR 835

4-foot8,54368125.680 CRI / 3500K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F32 T8 with HBF in a 4-foot strip
LSL 4 VH UV FR 840
ECL 4 VH UV FR 840

4-foot8,80768129.580 CRI / 4000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F32 T8 with HBF in a 4-foot strip
LSL 4 VH UV FR 850
ECL 4 VH UV FR 850

4-foot9,07168133.480 CRI / 5000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F32 T8 with HBF in a 4-foot strip
LSL 6 LW UV FR 835

ECL 6 LW UV FR 835

6-foot2,99422136.180 CRI / 3500K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 2-lamp F25 T8 with LBF in a 6-foot strip
LSL 6 LW UV FR 840

ECL 6 LW UV FR 840

6-foot3,08622140.380 CRI / 4000K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 2-lamp F25 T8 with LBF in a 6-foot strip
LSL 6 LW UV FR 850

ECL 6 LW UV FR 850

6-foot3,17922144.580 CRI / 5000K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 2-lamp F25 T8 with LBF in a 6-foot strip
LSL 6 MD UV FR 835

ECL 6 MD UV FR 835

6-foot6,22154115.280 CRI / 3500K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 4-lamp F25 T8 with NBF in a 6-foot strip
LSL 6 MD UV FR 840

ECL 6 MD UV FR 840

6-foot6,41354118.880 CRI / 4000K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 4-lamp F25 T8 with NBF in a 6-foot strip
LSL 6 MD UV FR 850

ECL 6 MD UV FR 850

6-foot6,60654122.380 CRI / 5000K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 4-lamp F25 T8 with NBF in a 6-foot strip
LSL 6 HI UV FR 835

ECL 6 HI UV FR 835

6-foot9,45770135.180 CRI / 3500K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 6-lamp F25 T8 with NBF in a 6-foot strip
LSL 6 HI UV FR 840

ECL 6 HI UV FR 840

6-foot9,75070139.380 CRI / 4000K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 6-lamp F25 T8 with NBF in a 6-foot strip
LSL 6 HI UV FR 850

ECL 6 HI UV FR 850

6-foot10,04270143.580 CRI / 5000K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 6-lamp F25 T8 with NBF in a 6-foot strip
LSL 6 VH UV FR 835

ECL 6 VH UV FR 835

6-foot11,92395125.580 CRI / 3500K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 8-lamp F25 T8 with NBF in a 6-foot strip
LSL 6 VH UV FR 840

ECL 6 VH UV FR 840

6-foot12,29295129.480 CRI / 4000K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 8-lamp F25 T8 with NBF in a 6-foot strip
LSL 6 VH UV FR 850

ECL 6 VH UV FR 850

6-foot12,66095133.380 CRI / 5000K120-277V, 347VNoUp to 189,000 hrs (calculated)Replaces 8-lamp F25 T8 with NBF in a 6-foot strip
LSL 8 LW UV FR 835
ECL 8 LW UV FR 835

8-foot4,07030135.780 CRI / 3500K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 2-lamp F32 T8 with NBF in an 8-foot strip
LSL 8 LW UV FR 840
ECL 8 LW UV FR 840

8-foot4,19530139.880 CRI / 4000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 2-lamp F32 T8 with NBF in an 8-foot strip
LSL 8 LW UV FR 850
ECL 8 LW UV FR 850

8-foot4,3213014480 CRI / 5000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 2-lamp F32 T8 with NBF in an 8-foot strip
LSL 8 ML UV FR 835
ECL 8 ML UV FR 835

8-foot5,87844133.680 CRI / 3500K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 1-lamp F96 T8HO, or 1-lamp F96 T12HO, in an 8-foot strip
LSL 8 ML UV FR 840
ECL 8 ML UV FR 840

8-foot6,06044137.780 CRI / 4000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 1-lamp F96 T8HO, or 1-lamp F96 T12HO, in an 8-foot strip
LSL 8 ML UV FR 850
ECL 8 ML UV FR 850

8-foot6,24244141.980 CRI / 5000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 1-lamp F96 T8HO, or 1-lamp F96 T12HO, in an 8-foot strip
LSL 8 MD UV FR 835
ECL 8 MD UV FR 835

8-foot7,70964120.580 CRI / 3500K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F32 T8 with NBF, 2-lamp F54 T5HO, or 2-lamp F96 T8 in an 8-foot strip
LSL 8 MD UV FR 840
ECL 8 MD UV FR 840

8-foot7,94864124.280 CRI / 4000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F32 T8 with NBF, 2-lamp F54 T5HO, or 2-lamp F96 T8 in an 8-foot strip
LSL 8 MD UV FR 850
ECL 8 MD UV FR 850

8-foot8,18664127.980 CRI / 5000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F32 T8 with NBF, 2-lamp F54 T5HO, or 2-lamp F96 T8 in an 8-foot strip
LSL 8 MD HE UV FR 835
ECL 8 MD HE UV FR 835

8-foot7,72656137.380 CRI / 3500K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F32 T8 with NBF, 2-lamp F54 T5HO, or 2-lamp F96 T8 in an 8-foot strip
LSL 8 MD HE UV FR 840
ECL 8 MD HE UV FR 840

8-foot7,96556141.580 CRI / 4000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F32 T8 with NBF, 2-lamp F54 T5HO, or 2-lamp F96 T8 in an 8-foot strip
LSL 8 MD HE UV FR 850
ECL 8 MD HE UV FR 850

8-foot8,20456145.780 CRI / 5000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F32 T8 with NBF, 2-lamp F54 T5HO, or 2-lamp F96 T8 in an 8-foot strip
LSL 8 MH UV FR 835
ECL 8 MH UV FR 835

8-foot10,33178132.580 CRI / 3500K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F32 T8 with HBF, or 2-lamp F96 T12HO, in an 8-foot strip
LSL 8 MH UV FR 840
ECL 8 MH UV FR 840

8-foot10,65178136.680 CRI / 4000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F32 T8 with HBF, or 2-lamp F96 T12HO, in an 8-foot strip
LSL 8 MH UV FR 850
ECL 8 MH UV FR 850

8-foot10,97178140.680 CRI / 5000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F32 T8 with HBF, or 2-lamp F96 T12HO, in an 8-foot strip
LSL 8 HI UV FR 835
ECL 8 HI UV FR 835

8-foot11,91287136.980 CRI / 3500K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 2-lamp F96 T8HO in an 8-foot strip
LSL 8 HI UV FR 840
ECL 8 HI UV FR 840

8-foot12,28187141.280 CRI / 4000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 2-lamp F96 T8HO in an 8-foot strip
LSL 8 HI UV FR 850
ECL 8 HI UV FR 850

8-foot12,64987145.480 CRI / 5000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 2-lamp F96 T8HO in an 8-foot strip
LSL 8 VH UV FR 835
ECL 8 VH UV FR 835

8-foot16,619135123.180 CRI / 3500K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F54 T5HO in an 8-foot strip
LSL 8 VH UV FR 840
ECL 8 VH UV FR 840

8-foot17,133135126.980 CRI / 4000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F54 T5HO in an 8-foot strip
LSL 8 VH UV FR 850
ECL 8 VH UV FR 850

8-foot17,647135130.780 CRI / 5000K120-277V, 347VYesUp to 189,000 hrs (calculated)Replaces 4-lamp F54 T5HO in an 8-foot strip
*NOTE: Fixture equivalencies are estimates only and should be confirmed by photometric analysis or sample install to ensure adequate light levels are achieved.
